For wireless audio streaming, MA-505 PA System comes with a built-in Bluetooth music player. The speaker is suitable for public-address solutions for medium-to-large crowds, schools, places of worship, presentations, seminars and meetings, shopping center & trade-show presentations, and more.
Ideal Applications
· School classrooms & halls
· Places of worship
· Presentations, seminars and meetings
· Day-care activities; playground duty
· Indoor/outdoor gatherings
· Weddings & funeral services
· Shopping center & trade show presentations and promotions
· Street performers
· Aerobic and fitness centers
· Recreational and social activities
Model MA-505R1
Name Portable Wireless PA System
Max. SPL 105 dB
Drivers 1" Tweeter & 8" Woofer
Frequency Range 70 Hz – 14 kHz
Audio Inputs MIC IN: 1 × XLR, 1 × 1/4" (6.3 mm)
LINE IN: 1 × 1/8" (3.5 mm)
Audio Output LINE OUT: 1 × 1/8" (3.5 mm)
Amplifier Class D
Output Power 145 W RMS, 248 W peak
Receiver Modules Up to 4
Audio Players Bluetooth,(USBR/SD Player/Rec Function is optional DPM Series)
Transmitter Modules MTM-91, MTM-24, MTM-58 (optional)
Extension Speaker 1 × 1/4" (6.3 mm)
Other Functions VOP, TONE control, siren sound effect
Power Supply AC 100 – 240 V or DC 24 – 28 V
Battery Built-in Li-ion battery
Battery Indicator 4-segment indicators (25/50/75/100%)
Standby Time Up to 8 hours
Color Black
Dimensions 275 × 406 × 225 mm (W × H × D)
Weight Approx. 8.0 kg
Optional Accessories SC-505 carry bag, MS-70 tripod stand, MM-Series microphones
