Enjoy bright images in many environments with the ViewSonic PA503W 3600-Lumen WXGA DLP Projector. Its 3800 lumens of brightness can overcome ambient light in many situations, making it well suited for presentation areas such as boardrooms and classrooms. The 1280 x 800 WXGA native resolution is suitable for displaying many file and document types, and it will accept video signals up to Full HD (1920 x 1080) for higher resolution sources. The projector features a 1.55 to 1.7:1 throw ratio, which will allow you to place it near the back of the room in many installations.
The PA503W has one HDMI input for connecting digital high-definition sources such as Blu-ray players and HD cable/satellite boxes. It also has two VGA inputs for analog sources, and its VGA output will allow you to daisy-chain multiple projectors or displays so they can all display the same source. Analog audio input and output and an onboard 2W speaker ensures that audio accompanies your video. The projector includes a VGA cable and an IR remote control.
SuperColor for Enhanced Color Accuracy
ViewSonic's SuperColor technology features a six-segment color wheel and dynamic lamp control capabilities, helping to provide a wide color range.
3D Blu-ray Ready HDMI Input
This projector is suitable for connecting to any HDMI-enabled device, and can display 3D images directly from 3D Blu-ray players. 3D images can be viewed with optional ViewSonic PGD-350 Shutter Glasses, or any other compatible 3D glasses.
Quick Power Off
With the Quick Power Off feature enabled, the projector can be powered off in seconds rather than waiting for a cool-down cycle to complete. This lets users pack the projector away without having to worry about the internal fan still running.
Additional Features
Energy efficient SuperEco mode
Designed for reduced input latency
Image Display
Display System DLP
Native Chip Resolution 1280 x 800 (WXGA)
Supported Resolutions Minimum: VGA - 640 x 480
Maximum: Full HD 1080p - 1920 x 1080
Max Brightness 3800 Lumens
Aspect Ratio Native: 16:10
Dynamic Contrast Ratio 22,000:1
Color Depth 10-Bit (1.07 Billion Colors)
Scan Horizontal: 15 to 102 kHz
Vertical: 23 to 120 Hz
Lens
Focus Manual
Optical Zoom Manual: 1.1x
Throw Distance 3.248 - 36.024' / 0.99 - 10.98 m
Throw Ratio 1.55 to 1.7:1
Projection Size 30 - 300" / 76.20 - 762.00 cm
Features
Keystone Correction Vertical: ± 40°
Built-In Speaker Yes
Speaker Power 2W
Input/Output Connectors
Inputs/Outputs 1 x HDMI (HDMI Type-A) Audio, Video Input
2 x VGA (DE-15/DB-15) Video Input
1 x Composite (RCA) Video Input
1 x 1/8" / 3.5 mm Mini Audio Input
1 x VGA (DE-15/DB-15) Video Output
1 x 1/8" / 3.5 mm Mini Audio Output
1 x USB 2.0 (Mini-USB) Data Input
1 x RS-232 (DE-9/DB-9) Control Input
General
Lamp Power 190 W
Expected Lamp Life Medium Brightness: 5000 Hours
Low Brightness: 10,000 Hours
Security Cable Lock Slot
AC Input Power 120 to 240 VAC, 50 / 60 Hz
Power Consumption Medium Brightness: 260 W
Standby Mode (Lamp Off): < 0.5 W
Dimensions (W x H x D) 11.6 x 4.3 x 8.6" / 294.0 x 110.0 x 218.0 mm
Weight 4.89 lb / 2.22 kg
Packaging Info
Package Weight 7.06 lb
Box Dimensions (LxWxH) 14.3 x 11.8 x 7.55"
